Regulators for Ultra High Purity (UHP) AP/SL/AP/AZ
Process Gas Equipment AP Tech ? Process Gas EquipmentEquipment for the Semiconductor Industries ? N2 Gas/Air Supply Line
-
?For UHP gas delivery in semiconductor and other clean industries
?Body material: 316L SS secondary remelt or 316L SS
?Electropolished wetted parts
?External metal seal construction
Safety Instructions Process Gas Equipment/Common Precautions Series Variations Valve and Regulator Recommendations Technical Data/Glossary of Terms Green Procurement (RoHS)
| Series | Description | Type | Body material |
|---|---|---|---|
| AP | For Ultra High Purity | Single Stage Regulator | 316L SS secondary remelt |
| AP | For Ultra High Purity | Two Stage Regulator | 316L SS secondary remelt |
| AP | For Ultra High Purity | Pneumatic Actuation Pressure Regulator | 316L SS secondary remelt |
| SL | For Ultra High Purity | Single Stage Regulator | 316L SS secondary remelt |
| AZ | For Ultra High Purity | Single Stage Regulator | SUS316L |
| AZ | For Ultra High Purity | Pneumatic Actuation Pressure Regulator | SUS316L |
| AK | For General Applications | Single Stage Regulator | SUS316 |
| AK | For General Applications | Two Stage Regulator | SUS316 |
| AK | For General Applications | Pneumatic Actuation Pressure Regulator | SUS316 |
| BP | For Ultra High Purity | Back Pressure Regulator | SUS316 |
| BP | For General Applications· | Back Pressure Regulator | SUS316 |
Diaphragm Valve for Ultra High Purity AP
Process Gas Equipment AP Tech ? Process Gas EquipmentEquipment for the Semiconductor Industries ? N2 Gas/Air Supply Line
-
?For UHP gas delivery in semiconductor and other clean industries
?Used as a gas shutoff valve
?No spring is used for the wetted parts and the drive part is also separated from the diaphragm. Dead space in the flow path is small in order to suppress particle generation.
Safety Instructions Process Gas Equipment/Common Precautions Series Variations Valve and Regulator Recommendations Technical Data/Glossary of Terms Green Procurement (RoHS)
| Series | Description | Type | Body material |
|---|---|---|---|
| AP | For Ultra High Purity | Air Operated Type Diaphragm Valve | 316L SS secondary remelt |
| AP | For Ultra High Purity | Manually Operated Type Diaphragm Valve | 316L SS secondary remelt |
| AP | For Ultra High Purity | Metering Valve | 316L SS secondary remelt |
| AZ | For Ultra High Purity | Air Operated Type Diaphragm Valve | SUS316L |
| AZ | For Ultra High Purity | Manually Operated Type Diaphragm Valve | SUS316L |
| AZ | For Ultra High Purity | Metering Valve | SUS316L |
| AK | For General Applications | Air Operated Type Diaphragm Valve | SUS316 |
| AK | For General Applications | Manually Operated Type Diaphragm Valve | SUS316 |
| AK | For General Applications | Metering Valve | SUS316 |
Check Valve/Vacuum Generator/Flow Switch AP
Process Gas Equipment AP Tech ? Process Gas EquipmentEquipment for the Semiconductor Industries ? N2 Gas/Air Supply Line
-
[Check valve]
?Fluid backflow is prevented by back pressure.
?Unique design with only one moving part in the gas stream, an O-ring
?Springless structure suppresses particle generation by vibration or chattering and pressure fluctuations on the downstream side
[Vacuum generator]
?Vacuum generation equipment
?Applicable to the exhaustion of unnecessary gas remaining inside the piping during gas cylinder replacement
[Flow switch]
?Detects excess flow above a given flow rate caused by pipe breakage, etc.
Safety Instructions Process Gas Equipment/Common Precautions Series Variations Valve and Regulator Recommendations Technical Data/Glossary of Terms Green Procurement (RoHS)
| Series | Type | Body material |
|---|---|---|
| AP | Check Valve | 316L SS secondary remelt |
| AP | Vacuum Generators | 316L SS secondary remelt |
| AP | Flow Switches | 316L SS secondary remelt |
