Vacuum Equipment

Vacuum Equipment »  Vacuum Ejectors /Vacuum Pump Systems

Vacuum Ejectors /Vacuum Pump Systems

Vacuum Ejectors /Vacuum Pump Systems Vacuum Ejectors /Vacuum Pump Systems

Vacuum Ejectors /Vacuum Pump Systems

Vacuum Unit (Vacuum Generators) ZK2□A

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
    ?Supply valve: An N.O. specification has been added.
    　Can hold vacuum? even when the power goes out or is turned off
    　Prevents the sudden dropping of workpieces?
    　? Supposing the supply pressure is being maintained
    ?An IO-Link compatible pressure switch has been added.
    　Allows for ejector control with a single communication line
    　Reading of the device information and parameter batch settings are
    　possible.
    ?Compatible with ejector systems and vacuum pump systems
    ?Energy saving ejector
    　Air supply is cut-off when vacuum is reached.
    　Air consumption: 93% reduction (Under SMC’s measurement conditions)
    ?More efficient ejector: Suction flow increased by 50% (Compared to other
    　SMC 1-stage ejectors)
    ?Energy saving efficiency: 93% reduction
    ?Improved low noise and suction flow by adoption of a high-noise
    　reduction silencer
Ejector seriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)		Vacuum pump system series
ZK2□070.729242 to 40ZK2□00
ZK2□101.044402 to 50ZK2□00
ZK2□121.261582 to 125ZK2□00
ZK2□151.567902 to 150ZK2□00

Valve Manifold Integrated with Ejector System JSY1000-E

Directional Control Valves ? Pilot Operated 4/5 Port Solenoid Valves
Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: PROFINET Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: IO-Link Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: EtherCAT Compatible Products
    ?Spacer type ejector with additional high-noise reduction silencer [New]
    ?A vacuum release flow adjustment unit has been added.
    ?Compact all-in-one manifold
    　The devices have been integrated into one for applications in which an
    　actuator and vacuum suction are used together.
    ?EtherCAT?，IO-Link [New]，PROFINET? [New] compatible
    ?Wiring/piping saving through use of all-in-one manifold
    ?Installation area: 64% reduction
    ?Weight: 42% reduction
    ?Energy saving function
    　CO2 emissions (Air consumption): 90% reduction

    　?IO-Link Master
  • 2D/3D CAD

    The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.

    Click here for 2D/3D CAD
  • Valve Manifold Integrated with Ejector System JSY1000-E
    Manual
    Series View search result
    JSY1000-EView search result
  • Valve Manifold Integrated with Ejector System JSY1000-E
    Manifold
    Series View search result
    JSY1000-EView search result
SeriesFlow rate characteristics
4/2→3/5 (A/B→E)
C [dm3/(s?bar)]		Flow rate characteristics
4/2→3/5 (A/B→E)
b		Applicable
cylinder size		Power
consumption
(W)
JSY1000-E0.910.48φ400.2
(With power-saving circuit)

Vacuum Manifold for Fieldbus System ZKJ

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: PROFINET Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: EtherNet/IP Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: IO-Link Compatible Products
Industrial Device Communication Equipment/Wireless System ? Industrial Device Communication Equipment: EtherCAT Compatible Products
IO-Link Devices ? Vacuum Unit/Vacuum Manifold
    ?Vacuum pads and actuator driving can be controlled with a single
    　manifold [New]
    　?Positive pressure unit [New]
    　　5-port solenoid valve
    　?Vacuum unit
    　　Energy saving ejector　Air consumption: 92% reduction
    ?Fieldbus compatible
    　Space saving: Requires no separate input/output units
    　Reduced wiring time
    　Compatible protocols: PROFINET, IO-Link, EtherNet/IP, EtherCAT
    ?Exhaust sealing function
    　Quick workpiece release
    ?4 stations/8 stations/12 stations/16 stations manifold compatible
Ejector seriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]
ZKJ070.73126
ZKJ101.05348
ZKJ121.26368
ZKJ151.574102

Compact Vacuum Unit ZQ□A

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
IO-Link Devices ? Vacuum Manifold
    ?Vacuum pressure switch with energy saving function
    　Air consumption: 90% reduction (Based on SMC’s measurement
    　conditions)
    　Power consumption: 60% reduction [1 W (Existing model) → 0.4 W]
    　Vacuum release pressure: From 0 MPa [From 0.3 MPa (Existing model) →
    　From 0 MPa]
    　Copy function: Reduced setting labor, Minimized risk of setting mistakes
    ?Compatible with ejector systems and vacuum pump systems
    ?IO-Link compatible
Ejector seriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)		Vacuum pump system series
ZQ050.55152 to 13ZQ000□
ZQ070.710252 to 20ZQ000□
ZQ101.022472 to 32ZQ000□

Large Size Vacuum Module (Vacuum Generators) ZR

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
    ?Compatible with ejector systems and vacuum pump systems
    ?Necessary functions can be combined through a modular design.
    ?Double solenoids provide a self-holding function.
    ?Adaptable to manifold applications
    ?Functions such as a digital vacuum switch or a solenoid valve can be selected.
SeriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)		Vacuum pump system series
ZR1101.025532 to 32ZR100
ZR1131.342862 to 50ZR100
ZR1151.5631022 to 100ZR100
ZR1181.8741552 to 125ZR100
ZR1202.0951942 to 150ZR100

Compact Vacuum Unit (Vacuum Generators) ZB

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
IO-Link Devices ? Vacuum Manifold
    ?Compatible with ejector systems and vacuum pump systems
    ?Quick response: Response time of the valve 5 ms, vacuum response time
    　28 ms
    ?Energy saving: Air consumption reduced by 17%, Vacuum pressure
    　reached increased by 21%
    ?Compact/Lightweight: 46 g
    ?With vacuum pressure switch
    　Can copy to up to 10 switches simultaneously
    ?IO-Link compatible
Ejector seriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)		Vacuum pump system series
ZB030.323.52 to 8ZB00
ZB040.43.56.52 to 10ZB00
ZB050.54.5102 to 13ZB00
ZB060.67182 to 20ZB00

Compact Vacuum Ejector (Vacuum Generators) ZA

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
    ?Total width: 9.9 mm, Total length: 72.9 mm, Total height: 52.5 mm,
    　Weight: 50 g
    ?Can be installed on moving parts
    ?Improved response through the shortening of the length of the tube to the pad
    ?Adaptable to manifold applications
  • 2D/3D CAD

    The new SMC CAD SYSTEM, CADENAS, allows you to output 2D/3D CAD data with full part numbers in various data formats. Responses to part number selection has been greatly improved with the newly developed system.

    Click here for 2D/3D CAD
  • Compact Vacuum Ejector (Vacuum Generators) ZA
    Manual
    Series Nozzle diameter
    (mm)    		 View search result
    ZA1050.5View search result
    ZA1070.7View search result
SeriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)
ZA1050.54122 to 13
ZA1070.78282 to 20

Vacuum Module (Vacuum Generators) ZX

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
    ?Compatible with ejector systems and vacuum pump systems
    ?Necessary functions can be combined through a modular design.
    ?Ideal for electronic parts or small precision parts weighing up to 100 g
    ?Adaptable to manifold applications

    ? The ZX (Digital pressure switch ZSE3 product) was discontinued
    　in June 2019.
    　Please select the ZQ series, ZK series.
SeriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)		Vacuum pump system series
ZX1050.55132 to 13ZX100
ZX1070.710232 to 20ZX100
ZX1101.022462 to 25ZX100

Vacuum Ejector (Vacuum Generators) ZM

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
    ?Valves and switches are unitized.
    ?Adaptable to manifold applications
    ?Maximum absorption flow rate has been increased by 40%.
    ?Max. vacuum pressure: ?84 kPa
SeriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]		Guidelines for applicable pad
(mm)
ZM050.515172 to 16
ZM070.723332 to 25
ZM101.038602 to 32
ZM131.344852 to 40
ZM151.5451102 to 50

Multistage Ejector (With built-in ZSE30A vacuum pressure switch) ZL1/ZL3/ZL6

Vacuum Equipment (Vacuum Generators/Vacuum Suction Cups/Other) ? Vacuum Ejectors (Vacuum Generators)/Vacuum Pump Systems
Features

The ZL multistage ejector (with built-in ZSE30A)
is to be discontinued as of August 2024. Select
the new ZL (with built-in ZSE20A) instead.　　　　　　　　
    ?Max. suction flow rate: 3 types available: 100, 300, and 600 L/min (ANR)
    ?Air consumption: 91% reduction (For the ZL3, ZL6)
    ?Weight: Max. 60% reduction [ZL112 (Existing model): 450 g → ZL1: 180 g]
    ?3-stage diffuser construction (For the ZL1: SMC comparison)
    　Suction flow rate increased by 250%
    ?3 types of vacuum pressure sensors
    ?No tools are required! Maintenance labor can be reduced.
    ?IO-Link compatible vacuum pressure switch

    *1 ZL3H, ZL6H (Standard supply pressure: 0.5 MPa)
    *2 Branch + Port exhaust
SeriesNozzle diameter
(mm)		Max. suction flow
[L/min(ANR)]		Air consumption
[L/min(ANR)]
ZL11.210057
ZL31.9
1.5		300?2135?1
ZL61.9 x 2
1.5 x 2		600?2270?1
